Large Stock Steel Reinforcement Bars Hot Ribbed HRB400 10mm / 12mm / 16mm
Place of Origin | Wuxi, China |
---|---|
Brand Name | Hengsai |
Certification | ASTM |
Model Number | 6mm 8mm 10mm 12mm 16mm 20mm |
Minimum Order Quantity | 5 Tons |
Price | Negotiable |
Packaging Details | Waterproof and rust-proof seaworthy packaged goods according to customer requirements |
Delivery Time | 7days |
Payment Terms | L/C, T/T, Western Union |
Supply Ability | 1000 tons/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xStandard | AiSi ASTM JIS EN DIN | Grade | HRB400 HRB500 |
---|---|---|---|
Length | 6-12m | Application | Buliding Bridge House Decoration |
Processing Service | Bending, Welding, Decoiling, Cutting, Punching | Material | HRB335 HRB400 HRB400E HRB500 |
Technique | Hot Ribbed Steel Rebar | Keyword | Steel Reinforcement Bars |
High Light | Hot Ribbed steel reinforcement bars,HRB400 steel reinforcement bars,10mm steel reinforcement bars |
Product Features
Rebar (short for reinforcing bar), known when massed as reinforcing steel or reinforcement steel,steel reinforcement bar is a steel bar used as a tension device in reinforced concrete and reinforced masonry structures to strengthen and aid the concrete under tension. Concrete is strong under compression, but has low tensile strength. Rebar significantly increases the tensile strength of the structure. Rebar's surface features a continuous series of ribs, lugs or indentations to promote a better bond with the concrete and reduce the risk of slippage.
We are a professional supplier of steel reinforcement bars.We offer quick delivery times on all our steel reinforcement bars products, so you can be sure you’ll get your order when you need it. For more information on our steel reinforcement bars or for a quote, please contact us today.
Specification
ASTM | A615/A615M/Gr60 |
Steel grade | HRB400, HRB500, HRB400E, HRB500E |
JIS | SD295/SD340/SD390 |
Section Shape | Spiral Shape,Herringbone Shap,Crescent Shape |
Dimensions | 6/8/10/12/15/16/18/20/22/...Customer requirements |
Length | 2000-12000mm,or as required |
Standard | ASTM,AISI,JIS,GB, DIN,EN |
Surface treatment | Black/Peeling/Polishing/Machined |
Technique | Cold/Hot rolled, Cold-Drawn, or Hot Forged |
Heat Treatment | Annealed; Quenched; Tempered |
price terms | FOB,CRF,CIF,EXW all acceptable |
Loading port | any port in China |
Packing | standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
Shape | Straight, coil |
U.S. rebar size chart
Imperial | Metric bar | Linear Mass Density | Nominal diameter | Nominal area | |||
bar size | size (soft) | lb⁄ft | kg⁄m | (in) | (mm) | (in²) | (mm²) |
#2 | No.6 | 0.167 | 0.249 | 0.250 = 2⁄8 = 1⁄4 | 6.35 | 0.05 | 32 |
#3 | No.10 | 0.376 | 0.56 | 0.375 = 3⁄8 | 9.53 | 0.11 | 71 |
#4 | No.13 | 0.668 | 0.994 | 0.500 = 4⁄8 = 1⁄2 | 12.7 | 0.2 | 129 |
#5 | No.16 | 1.043 | 1.552 | 0.625 = 5⁄8 | 15.9 | 0.31 | 200 |
#6 | No.19 | 1.502 | 2.235 | 0.750 = 6⁄8 = 3⁄4 | 19.1 | 0.44 | 284 |
#7 | No.22 | 2.044 | 3.042 | 0.875 = 7⁄8 | 22.2 | 0.6 | 387 |
#8 | No.25 | 2.67 | 3.973 | 1.000 = 8⁄8 | 25.4 | 0.79 | 510 |
#9 | No.29 | 3.4 | 5.06 | 1.128 ≈ 9⁄8 | 28.7 | 1 | 645 |
#10 | No.32 | 4.303 | 6.404 | 1.270 ≈ 10⁄8 | 32.3 | 1.27 | 819 |
#11 | No.36 | 5.313 | 7.907 | 1.410 ≈ 11⁄8 | 35.8 | 1.56 | 1,006 |
#14 | No.43 | 7.65 | 11.384 | 1.693 ≈ 14⁄8 | 43 | 2.25 | 1,452 |
#18 | No.57 | 13.6 | 20.239 | 2.257 ≈ 18⁄8 | 57.3 | 4 | 2,581 |
Canadian sizes
Metric | Linear Mass Density | Nominal diameter | Cross-sectional |
bar size | (kg/m) | (mm) | Area (mm²) |
10M | 0.785 | 11.3 | 100 |
15M | 1.57 | 16 | 200 |
20M | 2.355 | 19.5 | 300 |
25M | 3.925 | 25.2 | 500 |
30M | 5.495 | 29.9 | 700 |
35M | 7.85 | 35.7 | 1000 |
45M | 11.775 | 43.7 | 1500 |
55M | 19.625 | 56.4 | 2500 |
European sizes
Metric | Linear mass | Nominal | Cross-sectional |
bar size | density (kg/m) | diameter (mm) | area (mm²) |
6,0 | 0.222 | 6 | 28.3 |
8,0 | 0.395 | 8 | 50.3 |
10,0 | 0.617 | 10 | 78.5 |
12,0 | 0.888 | 12 | 113 |
14,0 | 1.21 | 14 | 154 |
16,0 | 1.58 | 16 | 201 |
20,0 | 2.47 | 20 | 314 |
25,0 | 3.85 | 25 | 491 |
28,0 | 4.83 | 28 | 616 |
32,0 | 6.31 | 32 | 804 |
40,0 | 9.86 | 40 | 1257 |
50,0 | 15.4 | 50 | 1963 |
Australian sizes
Nominal Diameter (mm) | Cross-sectional area (mm sq) | Mass per metre length, kg/m |
12 | 113 | 0.888 |
16 | 201 | 1.58 |
20 | 314 | 2.47 |
24 | 452 | 3.55 |
28 | 616 | 4.83 |
32 | 804 | 6.31 |
36 | 1020 | 7.99 |
Packing&Delivery
About Us
our company has passed ISO9001 international quality management system certification, and has more than 6 quality system certifications ,including provincial enterprise credit certificate, enterprise credit certificate, quality service certificate, integrity management demonstration units.
In recent years, the company has always occupied the market with high-quality products, Our products are sold throughout the country and exported to Southeast Asia, Central Asia, North Africa, South America and other regions. Welcome you and international friends to inquire for a better future!
FAQ:
Q1. What are your company's main products ?
A1: Our main products are steel reinforcement bars, Cold Rolled Stainless Steel Sheet, Hot Rolled Stainless Steel Sheet, Stainless Steel Coil Strip, Stainless Steel Bar Rod, etc.
Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.
Q3: What is the terms of packing?
A3: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.
Q4:What is your delivery time?
A4: For stocks, we could transport the goods to loading port within 7 days after we received your deposit
For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q5. What are the advantages of your company ?
A35: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q6. How many coutries you already exported ?
A6: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan etc.
Q7. Can you provide sample ?
A7: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
