ASTM EN DIN Welded Pipe ISO JIS With Bright Anneal 150mm

  • ASTM EN DIN Welded Pipe ISO JIS With Bright Anneal 150mm
  • ASTM EN DIN Welded Pipe ISO JIS With Bright Anneal 150mm
  • ASTM EN DIN Welded Pipe ISO JIS With Bright Anneal 150mm
Place of Origin China
Brand Name Hengsai
Certification ce, RoHS, BIS, JIS, GS, ISO9001
Model Number 200,300,400 series
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details Waterproof and rust-proof seaworthy packaged goods according to customer requirements
Delivery Time within 7 working days
Payment Terms L/C, T/T, Western Union
Supply Ability 1000 tons/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Shape Pipe Surface BA/2B/NO.1/NO.3/NO.4
Connection Welded Material Stainless Steel
Wall Thickness 1mm-150mm(SCH10-XXS) Standard ASTM EN DIN GB ISO JIS
Surface Treatment Welded Processing Technology Cold Drawn,Cold Rolled,Bright Anneal Etc
Highlight

ASTM DIN Welded Pipe

,

150mm Welded Bright Pipe
Leave a Message
Product Description

Product Description:

Stainless steel welded pipe is a type of pipe made from stainless steel, usually with a diameter of 10mm to 2000mm, with a certain wall thickness and a certain length. It is made by welding steel plates together, with the surface finish of BA/2B/NO.1/NO.3/NO.4. The standard of stainless steel welded pipe is ASTM EN DIN GB ISO JIS. The wall thickness of these pipes range from 1mm to 150mm (SCH10-XXS). The pipe is made through cold drawn, cold rolled, bright anneal processing technology. Stainless steel welded pipe is one of the most popular steel pipes for many industries due to its excellent corrosion resistance, high strength, and other advantages.



Features:

  • Product Name: Stainless Steel Welded Pipe
  • Connection: Welded
  • Surface: BA/2B/NO.1/NO.3/NO.4
  • Surface Treatment: Welded
  • Material: Stainless Steel
  • Processing Technology: Cold Drawn, Cold Rolled, Bright Anneal Etc
Product Name Stainless Steel Welded Pipe
Production Process Cold Drawn,Cold Rolled,Bright Anneal etc
Type Welded
Standard ASTM EN DIN GB ISO JIS
Tolerance +/-0.05 ~+/0.02
Surface Pickling,Bright;
No.1,2B,No.4,BA,8K
Satin,Brush,Hairline,Mirror,Polished
180 grits,320 grits,400 grits,600 grits,800 grits polished
Application

1).Heat exahanger tube for petrochemical,chemical and ocean development
2).Industrial furnace and heater tubes
3).for gas turbine and prochemical processing
4).Condenser tubes,sulfuric and phosphoric acids tubes,API tubing
5).Construction and ornament
6).Acid production,waste incineration,FGD,paper processing industrial etc
Materials 200 series: 201,202,202Cu,204Cu,
300series:301,303/Cu,304/L/H,304Cu,305,309/S,310/S,316/L/H/Ti,321/H,347/H,330,
400 series: 409/L,410,416/F,420/F,430,431,440C,441,444,446,
600 series: 13-8ph,15-5ph,17-4ph,17-7ph(630,631),660A/B/C/D,
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760,2304,
LDX2101.LDX2404,LDX4404,904L
Others: 153Ma,254SMo,253Ma,654SMo,F15,Invar36,1J22,N4,N6 etc
Alloy : Alloy 20/28/31;
Hastelloy: Hastelloy B / B-2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N;
Haynes: Haynes 230/556/188;
Inconel: Inconel 100/600/601/602CA/617/625713/718738/X-750,Carpenter 20;
Incoloy: Incoloy 800/
800H/800HT/825/925/926;
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400/K500
Nitronic: Nitronic 40/50/60;
Nimonic: Nimonic 75/80A/90 ;



Chemical Composition

Grade C Si Mu P S Cr Ni MO Ti Other
201 ≤0.15 ≤1.00 5.50-7.50 ≤0.060 ≤0.030 16.0-18.0 3.50-5.50 - -
301 ≤0.15 ≤1.00 ≤2.00 ≤0.065 ≤0.030 16.0-18.0 6.0-8.0 ≤2.00 -
304 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.030 18.0-20.0 8.0-11.0 - -
304L ≤0.03 ≤1.00 ≤2.00 ≤0.035 ≤0.030 18.0-20.0 8.0-12.0 - -
304H ≤0.08 ≤1.00 ≤2.00 ≤0.035 ≤0.030 18.0-20.0 8.0-10.0 - -
316L ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.030 16.0-18.0 10.0-14.0 2.0-3.0 -
316Ti ≤0.08 ≤1.00 ≤2.00 ≤0.035 ≤0.030 16.0-19.0 11.0-14.0 1.80-2.50 ≥5×C%
317L ≤0.030 ≤1.00 ≤2.00 ≤0.045 ≤0.030 18.0-20.0 11.0-15.0 3.0-4.0 -
321 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.030 17.0-19.0 9.0-12.0 - ≥5×C%
321H 0.04-0.10 ≤0.75 ≤2.00 ≤0.045 ≤0.030 17.0-19.0 9.0-12.0 - 4×C-0.70
347H 0.04-0.10 ≤0.75 ≤2.00 ≤0.045 ≤0.030 17.0-19.0 9.0-13.0 - -
309S ≤0.08 ≤0.75 ≤2.00 ≤0.045 ≤0.030 22.0-24.0 12.0-15.0 -
310S ≤0.08 ≤1.50 ≤2.00 ≤0.045 ≤0.030 24.0-26.0 19.0-22.0 - -
904L ≤0.02 ≤1.00 ≤2.00 ≤0.045 ≤0.035 ≤23 ≤28 - -
2205 ≤0.03 ≤1.00 ≤2.00 ≤0.030 ≤0.015 21.0-23.0 4.5-6.5 2.90-3.50 -
2507 ≤0.03 ≤0.80 ≤1.20 ≤0.035 ≤0.020 24.0-26.0 6.0-8.0 3.0-5.0 -

Applications:

Stainless steel welded pipe is a versatile product made from Hengsai, a well-known brand in China, with a wide range of 200 series, 300 series and 400 series available. It is certified by ce, RoHS, BIS, JIS, GS and ISO9001, and the minimum order quantity is 1 Ton. The price is negotiable, and the packaging is waterproof and rust-proof, with seaworthy packages according to customer requirements. Delivery time is within 7 working days, and payment terms are L/C, T/T, and Western Union. With a production capability of 1000 tons/month, it is a reliable choice for businesses. The connection is welded, and it is available in pipe shape with wall thicknesses of 1mm-150mm(SCH10-XXS). The surface includes BA/2B/NO.1/NO.3/NO.4, and it is treated with welding.



Support and Services:

We provide technical support and services for Stainless Steel Welded Pipe, such as:

  • Inspection before delivery
  • Provide sample for testing
  • Provide technical training
  • Provide technical advice
  • Provide installation and maintenance instructions
  • Provide after-sales service
  • Provide warranty service


Packing and Shipping:

Packaging and Shipping

Stainless steel welded pipe is commonly packaged in bundles and secured with steel straps or wires. The bundles may be further wrapped and protected with plastic or other materials as needed. Depending on the size and weight of the pipe, it may also be shipped in crates or on wooden pallets.

The shipment of stainless steel welded pipes may be done by truck, rail, sea, and air freight. The carrier chosen for shipment can vary depending on the size and weight of the pipes and the delivery destination.

stainless steel welded pipe

FAQ:

FAQ:
Q1. What are your company's main products ?
A1: Our main products are Cold Rolled Stainless Steel Sheet, Hot Rolled Stainless Steel Sheet, Stainless Steel Coil Strip, Stainless Steel Bar Rod, etc.

Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.

Q3: What is the terms of packing?
A3: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.

Q4:What is your delivery time?
A4: For stocks, we could transport the goods to loading port within 7 days after we received your deposit
For production period, it usually takes about 7 days-10 days after receiving the deposit.

Q5. What are the advantages of your company ?
A35: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q6. How many coutries you already exported ?
A6: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan etc.

Q7. Can you provide sample ?
A7: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
