CE ISO 9001 Carbon Steel Profile 50mm-2000mm 5#-40#
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xModel Number | 5#-40# | Product Name | Carbon Steel Profile |
---|---|---|---|
Surface | Pre-galvanised/Hot Dipped Galvanised/Power Coated | Material | Q235; A36; SS400; ST37; SAE1006/1008; S275JR; Q345,S355JR; 16Mn; ST52 Etc.ect, Or Customized |
Length | 1000mm~8000mm Or Customized | Keyword | Carbon Steel Channel |
Tolerance | ±1% | Advantage | CE,ISO 9001, SGS, ABS, BV,etc |
High Light | ISO 9001 Carbon Steel Profile,CE Carbon Steel Profile,2000mm types of channel steel |
CE ISO 9001 Carbon Steel Profile 50mm~2000mm Or Customized 5#-40#
There are many benefits to using carbon steel Profile Channel in construction projects. The metal is strong and durable, making it an ideal choice for structural support. It is also easy to work with, which means that it can be cut and shaped to fit nearly any construction need.
In addition, carbon steel is one of the most affordable metals on the market, which makes it a budget-friendly building material.
Product Name
|
ASTM AISI JIS Galvanized U Beam Steel U Channel Structural Steel
|
Grade
|
Q235/Q355
|
Model Number
|
5#-40#
|
Shape
|
U Channel
|
Perforated Or Not
|
Not Perforated
|
Tolerance
|
±1%
|
Alloy Or Not
|
Is Alloy
|
Invoicing
|
by theoretical weight
|
Delivery Time
|
within 7 days
|
Standard
|
GB ASTM AISI DIN,etc
|
MOQ
|
1 Ton
|
Material
|
Q195-Q345/SPCC,etc
|
Length
|
6m-12m or customizable
|
Thickness
|
0.5mm-3.0mm or customizable
|
Type
|
Carbon Structural Steel
|
Payment terms
|
L/C T/T (30%DEPOSIT)
|
PRICE TERM
|
CIF CFR FOB EX-WORK
|
Advantage
|
CE,ISO 9001, SGS, ABS, BV,etc
|
** The sizes or thicknesses of Channel Steel can be customized, if you need additional information,
please don’t hesitate to contact us at any time.
|
|
** All standard products are supplied without inter paper & PVC film. If needed, please inform.
|
|
**If your quantity is smaller than our MOQ, kindly pls contact us for inquiry accordingly,
sometime we have small stock, thank you.
|
SIZE (mm) |
T1 (mm) |
T2 (mm) |
JIS Weight (kg/m) |
GB Weight (kg/m) |
100×100 | 6 | 8 | 16.9 | 17.2 |
125×125 | 6.5 | 9 | 23.6 | 23.8 |
150×75 | 5 | 7 | 14.0 | 14.3 |
148×100 | 6 | 9 | 20.7 | 21.4 |
150×150 | 7 | 10 | 31.1 | 31.9 |
175×90 | 5 | 8 | 18.0 | 18.2 |
175×175 | 7.5 | 11 | 40.4 | 40.3 |
194×150 | 6 | 9 | 29.9 | 31.2 |
198×99 | 4.5 | 7 | 17.8 | 18.5 |
200×100 | 5.5 | 8 | 20.9 | 21.7 |
200×200 | 8 | 12 | 49.9 | 50.5 |
200×204 | 12 | 12 | 56.2 | 56.7 |
248×124 | 5 | 8 | 25.1 | 25.8 |
250×125 | 6 | 9 | 29.0 | 29.7 |
244×175 | 7 | 11 | 43.6 | 44.1 |
250×250 | 9 | 14 | 71.8 | 72.4 |
250×255 | 14 | 14 | 81.6 | 82.2 |
298×149 | 5.5 | 8 | 32.0 | 32.6 |
300×150 | 6.5 | 9 | 36.7 | 37.3 |
294×200 | 8 | 12 | 55.8 | 57.3 |
298×201 | 9 | 14 | 64.4 | 65.9 |
300×300 | 10 | 15 | 93.0 | 94.5 |
294×302 | 12 | 12 | 83.4 | 85 |
300×305 | 15 | 15 | 105 | 106 |
346×174 | 6 | 9 | 41.2 | 41.8 |
350×175 | 7 | 11 | 49.4 | 50.0 |
340×250 | 9 | 14 | 78.1 | 79.7 |
344×348 | 10 | 16 | 113 | 115 |
350×350 | 12 | 19 | 135 | 137 |
396×199 | 7 | 11 | 56.1 | 56.7 |
400×200 | 8 | 13 | 65.4 | 66.0 |
390×300 | 10 | 16 | 105 | 107 |
388×402 | 15 | 15 | 140 | 141 |
394×398 | 11 | 18 | 147 | 147 |
400×400 | 13 | 21 | 172 | 172 |
400×408 | 21 | 21 | 197 | 197 |
414×405 | 18 | 28 | 232 | 233 |
428×407 | 20 | 35 | 283 | 284 |
446×199 | 8 | 12 | 65.1 | 66.7 |
450×200 | 9 | 14 | 74.9 | 76.5 |
440×300 | 11 | 18 | 121 | 124 |
496×199 | 9 | 14 | 77.9 | 79.5 |
500×200 | 10 | 16 | 88.2 | 89.6 |
506×201 | 11 | 19 | 102 | 103 |
482×300 | 11 | 15 | 111 | 115 |
488×300 | 11 | 18 | 125 | 129 |
600×200 | 11 | 17 | 103 | 106 |
596×199 | 10 | 15 | 92.5 | 95.1 |
606×201 | 12 | 20 | 118 | 120 |
582×300 | 12 | 17 | 133 | 137 |
588×300 | 12 | 20 | 147 | 151 |
594×302 | 14 | 23 | 170 | 175 |
692×300 | 13 | 20 | 163 | 166 |
700×300 | 13 | 24 | 182 | 185 |
800×300 | 14 | 26 | 207 | 210 |
808×302 | 16 | 30 | 241 | |
890×299 | 15 | 23 | 210 | 213 |
900×300 | 16 | 28 | 240 | 243 |
912×302 | 18 | 34 | 283 | 286 |
About Us
We are a leading manufacturer and exporter of metal materials. lt is a modern comprehensive service enterprise, which is specialized in the production and processing of stainless steel, carbon steel, and alloy steel, non-ferrous metals, metal products, and other metal material fields, as well as in the import and export sales and industrial technical services we have the world first-class processing equipment, modernized physical and chemical testing center, opening flat, cutting, surface treatment, molding, sheet metal, welding. machining and 8 big processing platform.
Moreover, we have the factory in shandong and jiangsu, facilitates each customer's comprehensive demand. Our company has successfully passed SO9001: China quality certification center quality certification since its establishment.Our products have been exported to many countries, such as the United States, Canada, Russia, Latvia, Ukraine, Brazil, Argentina,the united Arab emirates, Turkey, Saudi Arabia, Singapore, Indonesia,the Philippines, and enjoya high reputation!
FAQ:
Q1. What are your company's main products ?
A1: Our main products are Cold Rolled Stainless Steel Sheet, Hot Rolled Stainless Steel Sheet, Stainless Steel Coil Strip, Stainless Steel Bar Rod, etc.
Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.
Q3: What is the terms of packing?
A3: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.
Q4:What is your delivery time?
A4: For stocks, we could transport the goods to loading port within 7 days after we received your deposit
For production period, it usually takes about 7 days-10 days after receiving the deposit.
Q5. What are the advantages of your company ?
A35: We have many professionals, technical personnel, more competitive prices and best after-sales service than other stainless steel companies.
Q6. How many coutries you already exported ?
A6: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan etc.
Q7. Can you provide sample ?
A7: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
