C/H/T/U/Z Type Carbon Steel Profile 50mm-2000mm Hot Dipped Galvanised Power Coated

Place of Origin China
Minimum Order Quantity 5 Tons
Price Negotiable
Packaging Details Waterproof and rust-proof seaworthy packaged goods according to customer requirements
Delivery Time within 7 working days
Payment Terms L/C, T/T, Western Union
Supply Ability 1000 tons/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model Number 5#-40# Product Name Carbon Steel Profile
Surface Pre-galvanised/Hot Dipped Galvanised/Power Coated Widthness 50mm~2000mm Or Customized
Length 1000mm~8000mm Or Customized Keyword Carbon Steel Channel
Tolerance ±1% Advantage CE,ISO 9001, SGS, ABS, BV,etc
High Light

Carbon Steel Profile 50mm

,

Carbon Steel Profile 2000mm

,

CE l type steel channel

Leave a Message
Product Description

C/H/T/U/Z Type Carbon Steel Profile 50mm~2000mm Hot dipped galvanised/Power coated





Choosing the right carbon steel profile channel can be tricky. There are a few things you need to keep in mind when making your choice. Here are a few tips:

1. Make sure you know the application the carbon steel profile channel will be used for. This will help you narrow down your choices.

2. Consider the type of finish you want. There are many different finishes available, so make sure you choose one that meets your needs.

3. Pay attention to the width and thickness of the carbon steel profile channel. These dimensions will impact its strength and stability.

4. Choose a reputable manufacturer who can provide a quality product. Do your research to find a company with a good reputation.

5. Get quotes from multiple manufacturers before making your final decision. This will help you get the best price on your carbon steel profile channel.



Product Name
Mild Carbon Steel Channel
Material
Q235; A36; SS400; ST37; SAE1006/1008; S275JR; Q345,S355JR; 16Mn; ST52 etc.ect, Or Customized
Surface
Pre-galvanized/Hot dipped galvanised/Power coated
Shape
C/H/T/U/Z type
Thinckness
0.3mm-60mm
Widthness
50mm~2000mm or customized
Length
1000mm~8000mm or customized
Certifications
ISO 9001 BV SGS
Keyword
carbon steel channel
Packing
Industry standard packaging or according to client's requirement
Payment terms
30%T/T in advance, the balance against the B/L copy
Delivery time
Fast delievery in 7 days,up to order quantity







SIZE

(mm)

T1

(mm)

T2

(mm)

JIS Weight

(kg/m)

GB Weight

(kg/m)

100×100 6 8 16.9 17.2
125×125 6.5 9 23.6 23.8
150×75 5 7 14.0 14.3
148×100 6 9 20.7 21.4
150×150 7 10 31.1 31.9
175×90 5 8 18.0 18.2
175×175 7.5 11 40.4 40.3
194×150 6 9 29.9 31.2
198×99 4.5 7 17.8 18.5
200×100 5.5 8 20.9 21.7
200×200 8 12 49.9 50.5
200×204 12 12 56.2 56.7
248×124 5 8 25.1 25.8
250×125 6 9 29.0 29.7
244×175 7 11 43.6 44.1
250×250 9 14 71.8 72.4
250×255 14 14 81.6 82.2
298×149 5.5 8 32.0 32.6
300×150 6.5 9 36.7 37.3
294×200 8 12 55.8 57.3
298×201 9 14 64.4 65.9
300×300 10 15 93.0 94.5
294×302 12 12 83.4 85
300×305 15 15 105 106
346×174 6 9 41.2 41.8
350×175 7 11 49.4 50.0
340×250 9 14 78.1 79.7
344×348 10 16 113 115
350×350 12 19 135 137
396×199 7 11 56.1 56.7
400×200 8 13 65.4 66.0
390×300 10 16 105 107
388×402 15 15 140 141
394×398 11 18 147 147
400×400 13 21 172 172
400×408 21 21 197 197
414×405 18 28 232 233
428×407 20 35 283 284
446×199 8 12 65.1 66.7
450×200 9 14 74.9 76.5
440×300 11 18 121 124
496×199 9 14 77.9 79.5
500×200 10 16 88.2 89.6
506×201 11 19 102 103
482×300 11 15 111 115
488×300 11 18 125 129
600×200 11 17 103 106
596×199 10 15 92.5 95.1
606×201 12 20 118 120
582×300 12 17 133 137
588×300 12 20 147 151
594×302 14 23 170 175
692×300 13 20 163 166
700×300 13 24 182 185
800×300 14 26 207 210
808×302 16 30 241
890×299 15 23 210 213
900×300 16 28 240 243
912×302 18 34 283 286
