JIS G 3521 Spring Steel Wire Furniture Door Screen

Place of Origin China
Brand Name Hengsai
Minimum Order Quantity 5 Tons
Price Negotiable
Packaging Details Waterproof and rust-proof seaworthy packaged goods according to customer requirements
Delivery Time within 7 working days
Payment Terms L/C, T/T, Western Union
Supply Ability 1000 tons/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Steel Wire Wire Size 0.20-12.50 Mm
UNS Grade No. SAE1040, SAE1045,SAE1050, SAE1055, SAE1060, SAE1065, SAE1070, SAE1080,SAE1084. Usages Springs, Furniture, Door, Screen, Weaving, Spokes, Vehicle, Industrial
Chinese Standard GB.T 4357, GB/T 4358 Tolerance +/-0.01mm
High Light

JIS G 3521 Spring Steel Wire

,

Spring Steel Wire Furniture

,

Screen spring wires

Leave a Message
Product Description

DIN 17223-1 EN 10270-1 Metal Wire Roll High Carbon Spring Steel Wire 0.20-12.50 mm



High carbon spring steel wire is a popular choice for springs and other applications where high strength and hardness are required. This type of steel has a higher carbon content than other types of spring steel, which gives it superior strength and hardness.

It is also more resistant to wear and tear, making it ideal for applications where reliability and durability are important.



Standard
DIN 17223-1, EN 10270-1, JIS G 3521, IS 4454, A 227M, GB/T 4357, GB/T4358
Wire Size:
0.20-12.50 mm
Chinese Material
45#, 47A, 47B, 60#, 62A, 62B, 65#, 65Mn, 67A, 67B, 70#, 72A, 72B, 75#, 77A, 77B, 80#, 82A, 82B, 85#
Japanese Industrial Standard Steel Grade
SWRH 42A, SWRH 42B, SWRH 47A, SWRH 47B, SWRH 52A, SWRH 52B, SWRH 57A,
SWRH 57B, SWRH 62A, SWRH 62B, SWRH 67A , SWRH 67B, SWRH 72A, SWRH 72B,
SWRH 77A, SWRH 77B, SWRH82A, SWRH82B
UNS Grade No.:
SAE1040, SAE1045,SAE1050, SAE1055, SAE1060, SAE1065, SAE1070, SAE1080,SAE1084.
British Standard Steel Name:
C42D, C48D, C60D, C62D, C66D, C68D, C70D, C72D, C76D, C78D, C80D, C82D,C86D.
Springs Usage
Helical Springs(tension, compression and torsion springs), spring washers and other wire springs.
Garage door spring wire, Mattress steel wire, bed steel wire, sofa steel wire, Springs for mattress,
mattress frame wires, Pocket coil mattress wire, etc.
Other Usages
Springs, Furniture, Door, Screen, Weaving, Spokes, Vehicle, Industrial
Other Products Name
High Carbon Steel Wire, Spring Steel Wire, Coil Spring Steel Wire,.Spoke Steel Wire,
Nipple Steel Wire, Nipple Steel Wire, Black Steel Wire, Hard drawn steel wire,
Phosphated steel wire, Ungalanized Steel Wire, Medium Carbon Steel Wire, Low Carbon Steel Wire, etc.



Round steel wire for springs Patented cold drawn,carbon steel wire for springs Technical delivery conditions
DIN 17223
Wire grade
Nominal diameter
mm
Chemical composition (cast analysis)% by mass

C
Si max
Mn
P
S
Cu max
A
1.00 to 10.00
0.40 to 0.85
0.35
0.30 to 1.00
0.04
0.040
0.20
B
0.30 to 6.00
6.30 to 14.00 15.00 to 20.00
0.55 to 0.85
0.40 to 0.85
0.40 to 0.85
0.35
0.35
0.35
0.30 to 1.00
0.30 to 1.00
0.30 to 1.50
0.040
0.040
0.040
0.040
0.040
0.040
0.20
0.20
0.20
C
2.00 to 6.00
6.30 to 20.00
0.70 to 1.00
0.50 to 1.00
0.35
0.35
0.30 to 1.50
0.30 to 1.50
0.030
0.030
0.030
0.030
0.12
0.12
D
0.07 to 6.00
6.30 to 20.00
0.70 to 1.00
0.50 to 1.00
0.35
0.35
0.30 to 1.50
0.30 to 1.50
0.030
0.030
0.030
0.030
0.12
0.12



Steel wire for mechanical springs-patented cold drawn unalloyed spring steel wire
EN 10270-1:2001
Tensile strength
Static
Dynamic
Low Tensile strength
Medium Tensile strength
High Tensile strength
SL
SM
SH
-
DM
DH



JIS G 3521 Hard Drawn Steel Wire
Level

Diameter
Note
A
SW-A
From 0.08mm to 10.0mm
-
B
SW-B
From 0.08mm to 13.0mm
Mainly for static load springs
C
SW-C

Galvanized steel wire ACSR
Diameter mm Tensile Strebgth
No Less Than (MPA)
Strength For 1% Elongation
No Less Than
LD=250mm Elongation
Noless Than%
Zinc Coating Mass (g/m2)
1.44-1.60 1450 1310 3.0 200
1.60-1.90 1450 1310 3.0 210
1.90-2.30 1450 1310 3.0 220
2.30-2.70 1410 1280 3.5 230
2.70-3.10 1410 1280 3.5 240
3.10.3.50 1410 1240 4.0 260
3.50-3.90 1380 1170 4.0 270
3.90-4.50 1380 1170 4.0 275
4.50-4.80 1380 1170 4.0 300





About Us

We are a leading manufacturer and exporter of metal materials. lt is a modern comprehensive service enterprise, which is specialized in the production and processing of stainless steel, carbon steel, and alloy steel, non-ferrous metals, metal products, and other metal material fields, as well as in the import and export sales and industrial technical services we have the world first-class processing equipment, modernized physical and chemical testing center, opening flat, cutting, surface treatment, molding, sheet metal, welding. machining and 8 big processing platform.



Moreover, we have the factory in shandong and jiangsu, facilitates each customer's comprehensive demand. Our company has successfully passed SO9001: China quality certification center quality certification since its establishment.Our products have been exported to many countries, such as the United States, Canada, Russia, Latvia, Ukraine, Brazil, Argentina,the united Arab emirates, Turkey, Saudi Arabia, Singapore, Indonesia,the Philippines, and enjoya high reputation!

JIS G 3521 Spring Steel Wire Furniture Door Screen 0JIS G 3521 Spring Steel Wire Furniture Door Screen 1



FAQ:

Q1. What are your company's main products ?

A1: Our main products are Cold Rolled Stainless Steel Sheet, Hot Rolled Stainless Steel Sheet, Stainless Steel Coil Strip, Stainless Steel Bar Rod, etc.



Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.



Q3: What is the terms of packing?

A3: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.



Q4:What is your delivery time?

A4: For stocks, we could transport the goods to loading port within 7 days after we received your deposit

For production period, it usually takes about 7 days-10 days after receiving the deposit.



Q5. What are the advantages of your company ?

A35: We have many professionals, technical personnel, more competitive prices and best after-sales service than other stainless steel companies.



Q6. How many coutries you already exported ?

A6: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan etc.



Q7. Can you provide sample ?

A7: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
