47B High Carbon Spring Steel Wire 0.20-12.50mm A 227M GB/T 4357
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | Steel Wire | Standard | DIN 17223-1, EN 10270-1, JIS G 3521, IS 4454, A 227M, GB/T 4357, GB/T4358 |
---|---|---|---|
Wire Size | 0.20-12.50 Mm | Chinese Material | 45#, 47A, 47B, 60#, 62A, 62B, 65#, 65Mn, 67A, 67B, 70#, 72A, 72B, 75#, 77A, 77B, 80#, 82A, 82B, 85# |
UNS Grade No. | SAE1040, SAE1045,SAE1050, SAE1055, SAE1060, SAE1065, SAE1070, SAE1080,SAE1084. | Usages | Springs, Furniture, Door, Screen, Weaving, Spokes, Vehicle, Industrial |
Chinese Standard | GB.T 4357, GB/T 4358 | Alloy Or Not | Non-Alloy |
High Light | 47B high carbon spring steel wire,high carbon spring steel wire 0.20mm,12.50mm high carbon spring wire |
DIN 17223-1 EN 10270-1 Metal Wire Roll High Carbon Spring Steel Wire 0.20-12.50 mm
If you are in need of a spring steel wire supplier, there are many options available to choose from. One great option is Spring Steel Solutions. They offer a wide range of stainless steel spring wire products, as well as other products related to springs and wire products. They offer a variety of sizes and grades of stainless steel spring wire, so you can find the perfect one for your needs.
If you're looking for spring wire, there are a few things to keep in mind. First, what kind of stainless steel are you looking for? There are several grades of stainless steel, and each has its own properties and benefits. Second, what diameter wire do you need? The most common diameters are 0.005 inches (0.13mm) and 0.007 inches (0.18mm). Third, how much length do you need? The most common lengths are 25 feet (7.6m) and 50 feet (15.2m).
Product Name
|
1.5mm wire Metal Wire Roll High Carbon Spring Steel Wire
|
Standard
|
DIN 17223-1, EN 10270-1, JIS G 3521, IS 4454, A 227M, GB/T 4357, GB/T4358
|
Wire Size:
|
0.20-12.50 mm
|
Chinese Material
|
45#, 47A, 47B, 60#, 62A, 62B, 65#, 65Mn, 67A, 67B, 70#, 72A, 72B, 75#, 77A, 77B, 80#, 82A, 82B, 85#
|
Japanese Industrial Standard Steel Grade
|
SWRH 42A, SWRH 42B, SWRH 47A, SWRH 47B, SWRH 52A, SWRH 52B, SWRH 57A,
SWRH 57B, SWRH 62A, SWRH 62B, SWRH 67A , SWRH 67B, SWRH 72A, SWRH 72B,
SWRH 77A, SWRH 77B, SWRH82A, SWRH82B
|
UNS Grade No.:
|
SAE1040, SAE1045,SAE1050, SAE1055, SAE1060, SAE1065, SAE1070, SAE1080,SAE1084.
|
British Standard Steel Name:
|
C42D, C48D, C60D, C62D, C66D, C68D, C70D, C72D, C76D, C78D, C80D, C82D,C86D.
|
Springs Usage
|
Helical Springs(tension, compression and torsion springs), spring washers and other wire springs.
Garage door spring wire, Mattress steel wire, bed steel wire, sofa steel wire, Springs for mattress,
mattress frame wires, Pocket coil mattress wire, etc.
|
Other Usages
|
Springs, Furniture, Door, Screen, Weaving, Spokes, Vehicle, Industrial
|
Other Products Name
|
High Carbon Steel Wire, Spring Steel Wire, Coil Spring Steel Wire,.Spoke Steel Wire,
Nipple Steel Wire, Nipple Steel Wire, Black Steel Wire, Hard drawn steel wire,
Phosphated steel wire, Ungalanized Steel Wire, Medium Carbon Steel Wire, Low Carbon Steel Wire, etc.
|
Round steel wire for springs Patented cold drawn,carbon steel wire for springs Technical delivery conditions
|
DIN 17223
|
||||||
Wire grade
|
Nominal diameter
mm |
Chemical composition (cast analysis)% by mass
|
|
||||
C
|
Si max
|
Mn
|
P
|
S
|
Cu max
|
||
A
|
1.00 to 10.00
|
0.40 to 0.85
|
0.35
|
0.30 to 1.00
|
0.04
|
0.040
|
0.20
|
B
|
0.30 to 6.00
6.30 to 14.00 15.00 to 20.00 |
0.55 to 0.85
0.40 to 0.85 0.40 to 0.85 |
0.35
0.35 0.35 |
0.30 to 1.00
0.30 to 1.00 0.30 to 1.50 |
0.040
0.040 0.040 |
0.040
0.040 0.040 |
0.20
0.20 0.20 |
C
|
2.00 to 6.00
6.30 to 20.00 |
0.70 to 1.00
0.50 to 1.00 |
0.35
0.35 |
0.30 to 1.50
0.30 to 1.50 |
0.030
0.030 |
0.030
0.030 |
0.12
0.12 |
D
|
0.07 to 6.00
6.30 to 20.00 |
0.70 to 1.00
0.50 to 1.00 |
0.35
0.35 |
0.30 to 1.50
0.30 to 1.50 |
0.030
0.030 |
0.030
0.030 |
0.12
0.12 |
Steel wire for mechanical springs-patented cold drawn unalloyed spring steel wire
|
EN 10270-1:2001
|
|
Tensile strength
|
Static
|
Dynamic
|
Low Tensile strength
Medium Tensile strength High Tensile strength |
SL
SM SH |
-
DM DH |
JIS G 3521 Hard Drawn Steel Wire
|
|||
Level
|
|
Diameter
|
Note
|
A
|
SW-A
|
From 0.08mm to 10.0mm
|
-
|
B
|
SW-B
|
From 0.08mm to 13.0mm
|
Mainly for static load springs
|
C
|
SW-C
|
Galvanized steel wire ACSR | ||||
Diameter mm | Tensile Strebgth No Less Than (MPA) |
Strength For 1% Elongation No Less Than |
LD=250mm Elongation Noless Than% |
Zinc Coating Mass (g/m2) |
1.44-1.60 | 1450 | 1310 | 3.0 | 200 |
1.60-1.90 | 1450 | 1310 | 3.0 | 210 |
1.90-2.30 | 1450 | 1310 | 3.0 | 220 |
2.30-2.70 | 1410 | 1280 | 3.5 | 230 |
2.70-3.10 | 1410 | 1280 | 3.5 | 240 |
3.10.3.50 | 1410 | 1240 | 4.0 | 260 |
3.50-3.90 | 1380 | 1170 | 4.0 | 270 |
3.90-4.50 | 1380 | 1170 | 4.0 | 275 |
4.50-4.80 | 1380 | 1170 | 4.0 | 300 |
